MAGNETIC CHIP CONVEYOR
INTRODUCTION:
We are one of the highly established manufactures and suppliers of excellent quality precision
Magnetic Chip Conveyor
These magnetic chip conveyor are made up of super quality raw materials, which are procured from highly established raw material suppliers. We never compromise on the quality of products. Hence, we have a team of highly qualified professionals for quality test who stringently conducts quality test to ensure excellence of products. Our company offers these conveyors at very economic prices to gratify the customers across India.
Hinged steel belt chip conveyor:
Hinged steel belt chip conveyor has been specifically designed keeping in mind the hazards that are normally encountered with conventional chips and shaft conveyors. The hinged steel belt is pressed in extra heavy duty sheet and perfect guiding of rollers ensures minimum friction and noise free operation. The body compact in size and occupies small space but due to extra chip space can handle large volume of chips. The continuous operation ensures least machine down time and minimum labor.
Application:
CNC turning centers, cnc machining centers, transfer line, multi-spindle automates, spm's, heat treatment furnaces and press shops.
Magnetic plan sheet type conveyor:
Fine, light and sharp chips generated from gear shaves, gear hobbers, spline cutting machines, spm's, deep hole drilling machines, broaching machines, press shops and heat treatment shops. Coming with large amount of coolant tend to escape with the coolant and cause damage to the pump and effects surface finish. Plain sheet magnetic conveyors attract ferrous chips from coolant and separates coolant from chips. Thus the coolant is free from chips and the conveyor acts as magnetic filter for the coolant.
The moving permanent magnets mounted on endless chain underneath the stationery stainless steel sheet attract ferrous chips and slide them on plate to the discharge end. The coolant separated from chips flows to the coolant tank through an over flow so that even floating chips get attracted by moving magnets and get conveyed.
STAR TRACE SOLUTIONS PVT. LTD. magnetic plain sheet type conveyors being sleek in construction can be introduced into small cross sectional openings in machine tools. Since conveyors are custom built, different configuration and profiles can be made to suit specific applications.
Note:Technical data and specification subject to change. Special magnetic conveyors can be made on request of customer they have to simply send us their technical data and application, required for our engineers.
